DIR-655EOL EOS
Xtreme N™ Gigabit Router
Description
Best-in-class features
The D-Link DIR-655 Xtreme N™ Gigabit Router is an 802.11n compliant device that delivers up to 14x faster speeds1 and six times the range1 of 802.11g devices while staying backward compatible with 802.11g and 802.11b devices. Connect the Xtreme N™ Gigabit Router to a cable or DSL modem and share your high-speed Internet access with multiple computers, game consoles, and media players. Create a secure wireless network to share photos, files, music, videos, printers, and network storage. Powered by Xtreme N™ technology and equipped with three external antennas, this router provides superior wireless coverage for larger homes and offices. The DIR-655 also includes a 4-port 10/100/1000 Gigabit switch that connects Gigabit wired devices for lag-free network gaming and faster file transfers.
Intelligent QoS engine
With D-Link’s Intelligent QoS Technology, wired and wireless traffic is analyzed and separated into multiple data streams. The DIR-655’s embedded WISH Stream Engine improves wireless media streaming by moving time-sensitive tagged traffic to the front of the WMM queue and optimizing RF settings for optimal wireless throughput. WISH (Wireless Intelligent Stream Handling) automatically detects multimedia, VoIP, and online gaming applications, requiring no user configuration. It works transparently with other QoS technologies to immediately improve wireless media speed.
Advanced network security
The Xtreme N™ Gigabit Router supports the latest wireless security features to help prevent unauthorized access, be it from over a wireless network or the Internet. Support for WEP, WPA, and WPA2 standards ensure that you will be able to use the best possible encryption regardless of your client devices. In addition, the Xtreme N™ Gigabit Router utilizes Dual Active Firewalls (SPI and NAT) to prevent potential attacks from across the Internet.
Share a storage device, printer, or 3g mobile internet connection
Using the SharePort™ Network USB Utility, you can connect an external hard drive or multifunction printer to the router’s USB port to share disk space or printing and scanning functions among family members or a group of users. This USB port also supports compatible D-Link 3G adapters, so you can connect your router to a 3G mobile service to provide Internet access to a group while travelling.
General features
Standards
• IEEE 802.11n
• IEEE 802.11g
• IEEE 802.11b
• IEEE 802.3
• IEEE 802.3u
• IEEE 802.3ab
DEVICE INTERFACES
• 802.11n Wireless LAN
• 10/100/1000BASE-T Gigabit WAN port
• 4 10/100/1000BASE-T Gigabit LAN ports
• USB 2.0 port
ANTENNA TYPE
• 3 External 2 dBi RP-SMA dipole antennas
SECURITY
• 64/128-bit WEP
• WPA & WPA2 (Wi-Fi Protected Access)
ADVANCED FIREWALL FEATURES
• Network Address Translation (NAT)
• Stateful Packet Inspection (SPI)
• VPN Pass-Through/Multi-Sessions PPTP/L2TP/IPSec
QoS
• QoS engine for prioritizing traffic WISH Stream Engine
DEVICE MANAGEMENT and Monitoring
• UPnP support
• DDNS support
• Integrated Wireless Security Wizard
• Windows Connect Now (WCN) support
• Web-Based management using Internet Explorer 6 or later; Firefox 2.0 or later; or other Java-enabled browser
• Automatic firmware update notification
• E-mail notification for triggered events
• D-Link Network Monitor Yahoo! Widget
• D-Link Internet Usage Meter Yahoo! Widget
SharePort FUNCTION SUPPORT
• Allows connection of external hard drive or multifunction printer to USB port
• Allows sharing of HD space, printing and scanning functions
INSTALLATION
• Setup Wizard
• SharePortTM Network USB Utility
• Desktop or wall mount
SYSTEM REQUIREMENTS
Computer with:
Computer with:
• Pentium 3 800 GHz or better processor
• 256 MB RAM or higher
• Windows XP SP2/Vista/7, or Mac OS X v10.4 or higher
• CD-ROM drive
• SharePortTM Network USB Utility For optimal wireless performance:
• Rangebooster NTM 650 Adapter (DWA-645)
LEDs
• Power
• Status
• Internet / WAN
• WLAN
• LAN
• USB
DIMENSIONS (L x W x H)
• 120.5 x 198 x 32 mm (4.6 x 7.6 x 1.3 inches)
WEIGHT
• 341.5 grams (0.75 lb)
CERTIFICATIONS
• FCC Class B
• CE
• IC
• C-Tick
• IPv6 Ready
• Wi-Fi Certified
• WMM
• Compatible with Windows
Certificates
Order info
DIR-655 Xtreme N™ Gigabit Router
