External Fixed Dome Full HD IP-camera
Nereden Alınır


External Fixed Dome Full HD IP-Camera DCS-6314 is the ideal solution for creating a system of professional high-definition video, and security of small, medium and large enterprises. The camera is equipped with a two-megapixel high-sensitivity CMOS-sensor with progressive scan and supports WDR, which allows to obtain excellent image quality in all conditions. With its robust design, "all in one" camera ideally suited to the surveillance system and requires no additional accessories.
High Quality Video
To maximize bandwidth efficiency and higher image quality, DCS-6314 compresses the video in real time using the codec H.264, MPEG-4, MJPEG, and supports three separate profile for the simultaneous transmission of video in real time and recording . This property provides a wide range of applications for security cameras, for example, observation of public spaces for the detection of incidents and coordinating the response, control of restricted areas, deterring criminal activity or surveillance assets.
Continuous surveillance
Video Camera DCS-6314 with the WDR sensor delivers excellent image quality but with uneven lighting that allows the identification of the subject lit from behind, or shooting in very bright light. In dark places, ICR-cut filter is automatically shifted to the side to accept a wider range of light for video surveillance. Also, the camera DCS-6314 is equipped with a built-in infrared LEDs that allow the camera to observe, even in total darkness at a distance of 15 m The combination of these features makes the DCS-6314 an ideal solution for day and night surveillance.
Reliable management software
As with the camera DCS-6314 includes D-ViewCam - software for video surveillance systems, allowing you to view images, manage, and to record up to 32 cameras on a single computer. In addition, we can activate e-mail alerts when motion is detected or when the signal to the digital input.
Connection flexibility
Camera DCS-6314 is equipped with built-in PoE standard 802.3af, simplifying installation by providing a supply and connection to the network using one Ethernet-cable, and thus eliminating the need for drilling holes and laying additional cables. In addition, the digital inputs and outputs allow you to connect external devices such as IR sensors, switches and alarm relays.

Genel Özellikler

Fiziksel Özellikler
The exceptional quality of the video
• 1/2 inch, 8-megapixel CMOS-sensor with progressive scan
• Full HD resolution of 1920 x 1080
• WDR technology provides improved image quality
• codec support H.264, MPEG-4, MJPEG for streaming and recording
• Motion detection
• Private masks
Outdoor installation
• Built-in IR LEDs (15 m) for video surveillance in the dark
• A number of options for mounting the camera
• Rugged weatherproof casing (standard IP-68)
• Weather protection shield to protect the unit for outdoor installation
• Card slot MicroSD / SDHC
• Port 10/100 Fast Ethernet with support for PoE, providing easy integration into network
• Digital inputs and outputs for connecting external devices
• The audio input and audio output to connect a microphone and speaker for two-way audio transmission
Hardware profile camera
• 1/2 inch, 8-megapixel CMOS-sensor with progressive scan
• The distance infrared illumination: 15 m
• Minimum illumination: 0.2 Lux / F1.4 (Color)
• Minimum illumination: 0.05 lux / F1.4 (B & W)
• Minimum illumination: 0 lux (black-and-white mode with infrared illumination)
• Removable ICR-filter
• Varifocal lens: 2.8 mm to 12 mm
• The aperture of F1.4
• The minimum object distance of 0.2 m (width 2.8 mm)
• Viewing angle (16:9):
  96.5 °  ~ 31.2 °  (horizontal)
  + 64.5 °  ~ 17.8 °  (vertical)
  + 117.5 °  ~ 36.8 °  (diagonal)
• Adjustable in three axes:
  + 340 °  (rotation)
  + 75 °  (tilt)
  + 300 °  (rotation)
The camera body
• Weatherproof (standard IP-68) and anti-vandal (standard IK-10) body
• Weather protection hood
Image characteristics
• Setting the image size and quality, frame rate and bit rate
• The timings and paste text
• Customizable windows for motion detection
• Customizable zone private masks
• Set the exposure time, brightness, color saturation, contrast and sharpness
Video Compression
• Compression formats H.264/MPEG-4/MJPEG
• H.264/MPEG-4 multicast broadcasting
• JPEG for still images
Video Resolution
• 16:9 - 1920 x 1080, 1280 x 720, 800 x 450, 640 x 360, 480 x 270, 320 x 176, 176 x 144 and 30 frames / s
• 4:3 - 1440 x 1080, 1024 x 768, 800 x 600, 640 x 480, 320 x 240, 176 x 144 and 30 frames / s
Audio Support
• G.726
• G.711
Interfaces to external devices
• Port 10/100 BASE-TX Fast Ethernet with PoE
• 1 DI / 1 DO
• Output voltage: 12 V DC, 100 mA
• Card slot MicroSD / SDHC
• Audio In / Audio Out
Network Protocols
• IPv6
• IPv4
• TCP / IP
• DHCP-Client
• NTP-Client (D-Link)
• DNS-client
• DDNS-Client (D-Link)
• SMTP-client
• FTP-client
• Samba-client
• UPnP port forwarding
• Filtering IP-addresses
• QoS
• CoS
• Multicast
• Security administrator account and user groups
• Password authentication
• Encryption HTTP and RTSP
System requirements for Web-based interface
Web-browser: Internet Explorer, Firefox, Safari, Chrome
Event Management
• Motion detection
• Event notification and download stop-kadrov/videoklipov via email or FTP
• Support for multiple SMTP servers, and FTP
• Multiple event notifications
• Several ways to create backups
Remote management
• Create stop-kadrov/videoklipov and save to a local hard drive or NAS via Web-browser
• Interface settings, available through the Web-browser
Remote management
• Create stop-kadrov/videoklipov and save to a local hard drive or NAS via Web-browser
• Interface settings, available through the Web-browser
OS Support
Windows 8, 7, Vista, 2000 or XP
System Requirements D-ViewCam ™
• Operating System: Microsoft Windows 8/7/Vista/XP
• Web-browser: Internet Explorer 7 or above
• Protocol: Standard TCP / IP
The software features D-ViewCam ™
• Remote management / control of up to 32 cameras
• Viewing images on a single screen: up to 32 cameras
• Recording Options for triggering a sensor or manually
• Supports all management functions available through the Web-based interface

Fiziksel Özellikler

1,112 kg
• Input: 100-240 VAC, 50/60 Hz
• Output: 12V DC, 1.5A
Power consumption
10W ± 5%
• Operating: -30 °  to 50 °  C
• Storage: -20 °  to 70 °  C
• Operating: 20% to 80% (non-condensing)
• Storage: 5% to 95% (non-condensing)
• CE
• C-Tick
